Pounds of high temperature and high pressure power station valve is suitable for Class1500 3500Lb ~ ANSI, the operating temperature of -29 ~ 570 C, the oil, chemical, thermal power plants, and other operating conditions of the pipeline, cut off or connected to the media. Applicable medium: water, steam, etc.. Operating methods are: manual, gear, electric, etc..
1 product design and manufacture according to E101, ANSIB16.34 standard, can be equipped with the use of imported equipment.
2 valve in the cavity with a pressure self tight seal structure, the higher the internal pressure, the better the sealing performance. The 4 pipe ends the valve and the valve seat sealing surface with Stellite (Stellite) cobalt based alloy welding and sealing surface of the valve cover 6 stuffing reasonable depth, filler and inhibitor, reliable sealing, smooth switch.
7 valve with the structure to ensure that the valve is open to run without the valve stem leakage.
8 the opening and closing of the electric cut-off valve is controlled by the electric device, and the electric device is respectively equipped with a special motor, a speed reducer, a torque control mechanism, a field operating mechanism, a hand and an electric switching mechanism. In addition to the local operation, but also for remote operation.
Design and manufacturing: B16.34 E101 ANSI
Structure length: B16.10 E101 ANSI
Pressure temperature rating: B16.34 E101 ANSI
Experiment and test: E101 API598
