Flow rate, flow resistance small, no water hammer:
Y type design, the expansion of the valve cavity flow cross section, so that the valve cavity flow more smoothly, improve the flow rate of 30%.
Long service life:
Stem using 316L stainless steel, sealed with the contract type PTFE, automatic stem correction, automatic lubrication, maintenance free。
Pneumatic angle seat valve is the company's latest introduction of foreign advanced production technology, combined with modern industrial applications developed by the new generation of pneumatic angle seat valve. It is widely used in food and chemical processes, sterilization machine, high pressure sterilizer, dry cleaning machine, dryer, beer production line etc.. Compared with the traditional angle seat valve, it has the following new features:
1, visual position indicator: can be connected to a limit switch or emergency manual device.
2, easy to install: the gas control head can be used for 360 'rotation, or even a limit switch can also be 360'. One to two limit switches can be easily installed.
3, advanced pneumatic controller: thickening of the engineering plastic shell, safe and reliable. Low wear of the piston structure, large capacity and low air consumption. Internal components self lubrication, maintenance free.
4, with a variety of control methods: normally open, normally closed, double moving.
5, require smaller pneumatic actuator: fluid flow from the valve stem at the top of the inflow, the head.
6, easy to connect: MAMUR standard connection, embedded metal connectors. Optional smaller control head.
7, long-life Guide: Lease stem shaped Teflon (PTEE) sealed to prevent dirt into. Self lubrication, maintenance free. The stem is specially treated to ensure optimum fixation, and can automatically correct the position.
8, no water hammer effect: the flow from the bottom of the valve stem, water hammer (water impact force) was absorbed.
9, advanced body mechanism: flow ratio of 30%, smaller size, fluid flow pattern is better. 316 stainless steel body, Teflon seals, high temperature resistance, corrosion resistance. Life up to seven million L2000 series single action angle seat valve has the advantages of simple structure, beautiful appearance, quick installation and disassembly, rapid switching, flexible operation, small fluid resistance, safe and reliable use, etc..
All steel parts are made of acid resistant stainless steel, and the seal is made of silicone rubber or PTFE material, which is in line with the food hygiene standard. Widely used in food, wine, beverages, dairy products, fine chemicals, pharmaceutical and biological engineering, and many other industries.
Used in filling equipment, beverage, textile printing and dyeing, medical, pharmaceutical, sterilization, food industry, rubber machinery, HVAC etc..
