Eccentric spherical cock is the company introduced the latest international design concept and independent development of new products and technology with independent property rights. The valve adopts the half spherical structure, sedimentary particles can effectively remove the medium. Eccentric structure makes the valve open seat away from the ball valve speed and in the process of extending the service life of the seal. And the sealing surface spraying nickel alloy wear-resisting, increase service life. Apply to power plant, metallurgy, cement, paper and other industries in the pulverized coal conveying pipeline, ash, paper and other materials.
The valve body, valve cover, gland
Cock
valve seat
Bearing
Valve
Gray iron, ductile iron, carbon steel
Gray iron, ductile iron, carbon steel
Stainless steel, carbon steel +NBR
copper
Stainless steel, carbon steel +NBR
Nominal diameter DN:50-800mm
Nominal pressure PN:1.0MPa
Operating temperature: -19 DEG C -425 C
Applicable media: water, oil, sewage, liquid containing granular media
Drive: manual, electric, pneumatic
